Summary of TH series bucket elevator products.

TH series bucket elevator is suitable for conveying powder, granulated and small lump without cut and grinding cut small material. TH type is a kind of round link chain bucket elevator adopt the hybrid or gravity discharge, harvest type charging. Suitable for conveying bulk density is less than 1.5 t/m3 is easy to take out the powder, granulated and small lump materials at the bottom of the grinding cut. Such as coal, cement, gravel, sand, fertilizer, food, etc. TH type bucket elevator used for vertical transportation of various kinds of material. Suitable for conveying powder, granular, small block material, material temperature below 250 ℃.

TH series bucket elevator key features:

1. Easy maintenance, long service life. Casing steel plate thickening, good rigidity.

2. The conveying material temperature up to 250 ℃. Hoisting height stable and reliable operation, low noise, easy maintenance.

Section 3. In the case with a single channel and dual channel two forms. Improving models improve throughput is 30% greater than normal models.

4. Hoist chain using low alloy steel forging, and after carburizing and quenching processes, and have high tensile strength and wear resistance.

TH type bucket elevator is a kind of round link chain bucket elevator adopt the hybrid or gravity discharge, harvest type charging. Traction chain with high quality alloy steel high circle. Central casing of single and double channel within a machine two forms of heavy hammer tank automatic tension constant force. Sprocket using renewable rim composite structure. Long service life and easy rim change of jobs. Gravity automatic tensioning device for the bottom, can keep constant tension and avoid skid or take off the chain, hopper at the same time meet the stuck phenomenon caused by the accidental factors have certain let sex, can effectively protect the lower shaft parts, etc.

TH series bucket elevator has two hopper: ZH (in a deep bucket) generally applies to transport wet, easy to agglomerate, thrown harder materials, such as wet sand, sand, chemical fertilizers, base fertilizer, alkali powder, etc. SH type (deep bucket) generally applies to transport dry, loose easily throw materials, such as cement, gravel, coal, etc.

TH series bucket elevator drive device has two forms, respectively, with what ZJ had type reducer and ZQ type gear reducer. Reducer directly suit with what ZJ had type shaft in main shaft head, eliminating the transmission platform, coupling, etc., make the internal with compact structure, light weight, and different roller non-return device, non-return is reliable, the reducer low noise, smooth operation, and with the main shaft floating, can eliminate stress. The machine maximum throughput of 365 m3 / h, the biggest hoisting height is 50 m.
