Summary of NE plate chain bucket elevator.

NE plate chain bucket elevator to plate chain, gravity induced unloading lifting equipment. Suitable for vertical conveying powder, granular, small block cut or no grinding cut materials, such as raw material, cement, coal, limestone, clay, clinker, etc.

NE plate chain bucket elevator is the introduction of foreign advanced technology and develop new product; NE series plate chain bucket elevator used in the industrial countries, because of energy-efficient, NE plate chain bucket elevator is gradually replace the HL type ring chain hoist, etc. NE plate chain bucket elevator is flowing into type feeding, material into the hopper in the ascent to the top plate chain, the material under the action of gravity discharge itself. Main technical parameters of mechanical standard (JB3926-85). NE plate chain bucket elevator using the streaming charging, gravity discharge. The chain is high quality alloy high strength plate chain, wear and reliable. Driving part adopts hard tooth surface gear reducer. The hoisting machine is suitable for medium and large and have cut grinding materials such as limestone, cement clinker, gypsum and coal) vertical conveying, material temperature control under 250 ℃.

NE plate chain bucket elevator works:

NE series plate chain bucket elevator system into the type of feeding, material into the hopper by plate chain ascend to the top, in the material under the action of gravity discharge itself. This series hoist specification (a total of 11 NE15 ~ NE800) more wide lifting capacity; And can produce high, low energy consumption, the machine USES the whole sealing type casing chain speed is low, almost no back to the material, so the reactive power loss, low noise, long service life.

NE plate chain bucket elevator main structure:

Series of NE plate chain bucket elevator running parts, driving device, the upper device, central casing, the lower unit.

Run parts - composed of hopper and special plate chain, NE30 and adopt single chain, NE50 - NE800 with double row of chain.

Driving gear drive - driven by a variety of combinations, (depending on the user's actual needs). Drive platform equipped with repair aircraft and rail. Points in both left and right.

The upper device - installed orbit (double row chain), non-return device, discharge outlet is equipped with rubber back.

Middle section - part of the middle section is equipped with orbit (double chain), in order to prevent the chain of oscillation.
